Key Features
- PROFIBUS interface: 1 PROFIBUS interface, 1 port, with RS 485 and PROFINET IO not supported.
- Module capacity: PROFIBUS connection for max. 12 S7-1500 modules.
- Supply and protection: Rated value (DC) 24 V with permissible range 19.2 V to 28.8 V, reverse polarity protection, and short-circuit protection.
- Diagnostics: Status indicator, alarms, diagnostics function, RUN LED green, ERROR LED red, MAINT LED yellow, and Connection display DP green LED.
- Environmental design: Conformal coating, Class 2 for high reliability, Type 1 protection against fouling, and IPC-CC-830A Conformal coating, Class A.
Applications
- PROFIBUS-to-module connection: Provides a PROFIBUS connection for max. 12 S7-1500 modules.
Technical Summary
| Product type designation | IM 155-5 DP ST |
|---|---|
| Based on | 6ES7155-5BA00-0AB0 |
| PROFIBUS interfaces | 1; 1 port |
| Transmission rate, max. | 12 Mbit/s |
| Modules per rack, max. | 12; I/O modules |
| Rated value (DC) | 24 V |
| Permissible range, lower limit (DC) | 19.2 V |
| Permissible range, upper limit (DC) | 28.8 V |
Frequently Asked Questions
What is the Siemens 6AG1155-5BA00-2AB0 product type?
It is a SIPLUS ET 200MP IM155-5 DP ST interface module.
How many modules can the 6AG1155-5BA00-2AB0 connect?
It supports a PROFIBUS connection for max. 12 S7-1500 modules.
What interface and transmission rate does this module have?
It has 1 PROFIBUS interface with 1 port, RS 485, and a maximum transmission rate of 12 Mbit/s.
What supply voltage does the 6AG1155-5BA00-2AB0 require?
Rated value (DC) is 24 V, with a permissible range from 19.2 V to 28.8 V.
What are the main dimensions of the module?
Width is 35 mm, height is 147 mm, and depth is 129 mm.
