Key Features
- Managed Layer 2 IE switch: Manageable layer 2 IE switch with office features such as RSTP and VLAN.
- Industrial Ethernet and PROFINET functions: PROFINET IO device with PROFINET IO diagnosis, PROFINET conformity class B, and Ethernet/IP-compliant C-Plug slot.
- Port and management interfaces: 6x 100 Mbps RJ45 ports, 2x 100 Mbps ST/BFOC ports, 1x console port, web-based management, CLI, and port diagnostics.
- Redundancy and diagnostics: Supports redundancy functions, ring redundancy, media redundancy protocol (MRP), HRP, RSTP, MSTP, PRP, and diagnostics LEDs.
- Environmental protection and coating: Conformal coating, IP20 protection class, and chemical resistance to commercially available cooling lubricants, including airborne diesel and oil droplets.
Applications
- Industrial Ethernet network switching: Connects devices through 6x 100 Mbps RJ45 ports and 2x 100 Mbps ST/BFOC ports in an Industrial Ethernet network.
- PROFINET IO device integration: Supports PROFINET IO device connection and PROFINET IO diagnosis for network integration and troubleshooting.
- Managed ring and redundant network operation: Supports redundancy functions, ring redundancy, RSTP, MSTP, PRP, and MRP for redundant network structures.
- Network monitoring and administration: Provides web-based management, CLI, SNMP, port diagnostics, and statistics for network supervision.
Technical Summary
| Product type designation | XC206-2 |
|---|---|
| Transfer rate | 10, 100 Mbit/s |
| RJ45 ports | 6 |
| ST(BFOC) ports | 2 |
| Console port | 1 |
| Supply voltage | 24 V |
| Supply voltage range | 9.6 … 31.2 |
| Power loss | 6 W |
| Ambient temperature | -40 … +70 °C |
Frequently Asked Questions
What is Siemens 6AG1206-2BB00-7AC2?
It is a SIPLUS NET SCALANCE XC206-2 manageable layer 2 IE switch.
How many network ports does 6AG1206-2BB00-7AC2 have?
It has 6x 100 Mbps RJ45 ports and 2x 100 Mbps ST/BFOC ports.
What power supply does the XC206-2 use?
The supply voltage is 24 V DC, with a voltage range of 9.6 … 31.2.
What management and diagnostic functions are available?
It supports web-based management, CLI, MIB support, TRAPs via email, port diagnostics, and diagnostics LEDs.
Which mounting options are available for this switch?
It supports 35 mm DIN-rail mounting, wall mounting, S7-300 rail mounting, and S7-1500 rail mounting.
