Key Features
- Stabilized 24 V DC output: Provides 24 V DC rated output with 5 A rated current and 1 output.
- Wide-range input: Supports 120 – 240 V AC/DC input and 1-phase AC or DC supply voltage.
- Diagnostic interface: Includes a diagnostic interface with unidirectional communication to the higher-level control and analysis system.
- Protection and isolation: Has galvanic isolation between input and output, short-circuit proof output, and internal fuse protection.
Applications
- 24 V DC supply for S7-1200 systems: Provides stabilized 24 V DC power for an S7-1200 power module setup.
Technical Summary
| Product function | SIMATIC S7-1200 power module PM 1207 |
|---|---|
| Output voltage | 24 V |
| Output current | 5 A |
| Input voltage, AC | 120 … 240 V |
| Input voltage, DC | 120 … 240 V |
| Type of power supply network | 1-phase AC or DC |
| Number of outputs | 1 |
| Diagnostic interface | Yes |
| Communication function | Yes |
| Galvanic isolation between input and output | Yes |
| Protection class IP | IP20 |
| Efficiency | 88 % |
Frequently Asked Questions
What is Siemens 6EP3333-4SB00-3AX0?
It is a SIMATIC S7-1200 power module PM 1207 with a stabilized 24 V/5 A output.
What input voltage does 6EP3333-4SB00-3AX0 accept?
It accepts 120 – 240 V AC/DC input.
How many outputs does the PM 1207 have and what is the rated output current?
It has 1 output with a rated current of 5 A.
Does 6EP3333-4SB00-3AX0 include a diagnostic interface?
Yes. It includes a diagnostic interface with unidirectional communication to the higher-level control and analysis system.
