Key Features
- Analog output expansion for LOGO! 8: LOGO! AM2 AQ expansion module for LOGO! 8.
- 2 analog outputs: Provides 2 AO.
- Voltage and current output ranges: Supports 0-10 V, 0/4-20 mA output ranges.
- 24 V DC supply: Rated value (DC): 24 V.
- DIN rail mounting: Mounting on 35 mm DIN rail, 2 spacing units wide.
Applications
- LOGO! 8 analog output expansion: Adds 2 analog outputs to a LOGO! 8 system.
- 0-10 V signal output: Supplies 0-10 V analog output signals.
- 0/4-20 mA signal output: Supplies 0/4-20 mA analog output signals.
Technical Summary
| Product type | LOGO! AM2 AQ expansion module |
|---|---|
| Controller compatibility | LOGO! 8 |
| Number of analog outputs | 2 |
| Output range, voltage | 0-10 V |
| Output range, current | 0/4-20 mA |
| Rated value (DC) | 24 V |
| Current consumption, typ. | 82 mA |
| Power loss, typ. | 2 W; 0.4 … 2.0 W |
| Mounting | on 35 mm DIN rail, 2 spacing units wide |
| IP degree of protection | IP20 |
Frequently Asked Questions
What is Siemens 6ED1055-1MM00-0BA2?
It is a LOGO! AM2 AQ expansion module for LOGO! 8.
How many analog outputs does 6ED1055-1MM00-0BA2 provide?
It provides 2 analog outputs.
Which output ranges are supported by this module?
It supports 0-10 V and 0/4-20 mA output ranges.
What supply voltage does 6ED1055-1MM00-0BA2 use?
The rated value (DC) is 24 V.
How is the module mounted?
It mounts on a 35 mm DIN rail and is 2 spacing units wide.
